Laser marking

A rotary table is built into the system for marking cylindrical parts such as rings, bracelets and bearings. Our software provides precise circular motion.

Podczas laserowania różnych materiałów powstają różne toksyczne opary i cząsteczki. Opary, pył i cząsteczki muszą być usuwane w celu ochrony operatora i zapewnienia jakości aplikacji. Zsynchronizowana praca z laserem Możliwość zamontowania dodatkowego filtra HEPA do wyciągu oparów Zamykana konstrukcja szafki Recykling cząstek generowanych podczas procesów cięcia i grawerowania metali Various toxic fumes and particles are generated during the lasing of different materials. Vapors, dust and particles must be removed to protect the operator and ensure the quality of the application. Synchronized laser operation Additional HEPA filter can be installed for fume extraction Lockable cabinet design Recycling of particles generated during metal cutting and engraving processes Precious metals by collecting them in a tank szlachetnych poprzez gromadzenie ich w zbiorniku

The clamping device minimizes part movement caused by thermal expansion that occurs during the marking and cutting process. Adjustable width Pneumatic clamps, 6 bar pressure Easy access to the work area Laser safety glass enclosure for 1064 nm beam protection Drawer allows easy recovery of cut parts

You can engrave and cut objects from sheet metal continuously, without having to reposition the part in each cycle. Pneumatic valves and motorized motion Faster process without operator involvement Continuous operation possible Drawer allows easy retrieval of cut parts

The XY stage offers a much larger marking area (up to 500 mm x 500 mm). XY stage travel requirements can be produced in any size and precision according to customer application requirements.

Autofocus adjusts the distance from the workpiece. The system can automatically adjust the focus distance using a laser displacement sensor.
